I. Why we need Positional Encoding?
Unlike RNN/LSTM or CNN, which has natural “sense of ordering” because whether they process tokens one by one or each convolution sees local neighbors, attention does not contain these things. Therefore, authors of paper (Vaswani et al., 2017) have decided to add positional embeddings to input embedding, right before feeding to Attention stack (both in Encoder and Decoder).
According to several sources, for example (Kazemnejad, 2019), there are a few requirements of positional encoding function
- It should be bounded and unique.
- It should represent a relative position, meaning the dot product (attention score) between the embeddings of tokens \(i\) and \(j\) should depend only on \(i - j\).
II. Detail
Let say we have \(N\) token embeddings, each of them has dimension \(d\), \(d\) is even.
Positional encoding is defined as matrix \(P \in \mathbb{R}^{N \times d}\), in which:
\(\begin{equation} \label{eq:pe-formula} P_{ij} = \begin{cases} \sin\!\left(\dfrac{i}{10000^{j/d}}\right) & \text{if } j \text{ is even} \\[8pt] \cos\!\left(\dfrac{i}{10000^{(j-1)/d}}\right) & \text{if } j \text{ is odd} \end{cases} \end{equation}\)
III. Intuition on why this works
The following argument is inspired by (Kazemnejad, 2019).
So for each token embedding, we want our position encoding to have same dimension as the embedding (\(d\)). So we should find a way to convert position index (1, 2, …) to a high dimensional vector. Binary base seems to be a good choice
1 : 0 0 0 1 9 : 1 0 0 1
2 : 0 0 1 0 10 : 1 0 1 0
3 : 0 0 1 1 11 : 1 0 1 1
4 : 0 1 0 0 12 : 1 1 0 0
5 : 0 1 0 1 13 : 1 1 0 1
6 : 0 1 1 0 14 : 1 1 1 0
7 : 0 1 1 1 15 : 1 1 1 1
Here we are assuming \(d=4\) but we can generalize to higher \(d\) by simply padding 0 on the left of the binary representation. There are 2 interesting observations here. Firstly, if we fix the binary position, then across different number 1,2, …, the digit oscillate, and the frequency decreases as binary position increases.
However, the change in binary representation is too abrupt and neural networks prefer continuous changes because gradients behave better. So we have to come up with a continuous function that rotates when \(i\) (number/position) increases. We naturally think of the \(\sin\) function, for example, something like \(\sin(i)\). Moreover, the frequency should depend on \(j\), so I guess that is how the authors of (Vaswani et al., 2017) add the \(\frac{i}{10000^{j/d}}\) part.
Here is an image of the \(\sin\) curves when \(j\) varies.
Remark. You may wonder why $\eqref{eq:pe-formula}$ alternates between $\sin$ and $\cos$ rather than using $\sin$ for all dimensions. A key reason is that pairing $\sin$ and $\cos$ allows the dot product between two positional encodings to depend only on the relative distance $i - j$, directly satisfying Condition 2. The proof is as follows.
\[\mathrm{PE}(p) = \Bigl( \sin\!\bigl(p/\omega_1\bigr),\, \cos\!\bigl(p/\omega_1\bigr),\, \sin\!\bigl(p/\omega_2\bigr),\, \cos\!\bigl(p/\omega_2\bigr),\, \dots,\, \sin\!\bigl(p/\omega_m\bigr),\, \cos\!\bigl(p/\omega_m\bigr) \Bigr),\]where each $\omega_k$ is a frequency scale. Then for two positions $i$ and $j$, their dot product is
\[\mathrm{PE}(i)\cdot \mathrm{PE}(j) = \sum_{k=1}^m \left[ \sin\!\bigl(i/\omega_k\bigr)\sin\!\bigl(j/\omega_k\bigr) + \cos\!\bigl(i/\omega_k\bigr)\cos\!\bigl(j/\omega_k\bigr) \right].\]Applying the identity $\cos(a-b)=\cos a \cos b + \sin a \sin b$ with $a = i/\omega_k$, $b = j/\omega_k$, each bracket collapses to
\[\sin\!\bigl(i/\omega_k\bigr)\sin\!\bigl(j/\omega_k\bigr) + \cos\!\bigl(i/\omega_k\bigr)\cos\!\bigl(j/\omega_k\bigr) = \cos\!\left(\frac{i-j}{\omega_k}\right).\]Therefore,
\[\mathrm{PE}(i)\cdot \mathrm{PE}(j) = \sum_{k=1}^m \cos\!\left(\frac{i-j}{\omega_k}\right).\]Hence, the dot product depends only on the relative distance $i-j$, not on the absolute positions themselves.
